Özellikler
| Slide Travel XxYxZ-Axis | (360×2)×(420+100×2)×(350×2) mm |
|---|---|
| Height of Spindle Nose from Table | 250-600 mm |
| Table size (WxL) | 420×420×2mm |
| Tables Max.Load Capacity | 300×2kgs |
| Max. Spindle Speed | 10,000 min-1 |
| Rigid-Tap Speed | 5,000 min-1 |
| Spindle Motor | 15/11/7.5/5.5 KW |
| Rapid Traverse Rate X,Y,Z-Axis | 50,50,50 m/min |
| Shank of Tool Holders | BT40+P40T-II |
| Tool Change Method | Magazine direct system |
| No. of Tool Pot | 10×2(Op 12x2) |
| Max. Tool Diameter x Tool Length | φ80×180 mm |
| Max. Tool weight (total) | 4.0 kgs |
| Tool Change Time Tool to Tool/Chip to Chip | 1.2/2.5 sec |
| Max. Height of Machine | 2,600 mm |
| Height in Transporation | 2,275 mm |
| Size of Machine (Width, Depth) | 2,200×2,225 mm |
| Machine weight | 5,900 kgs |
| NC unit | (Op. FANUC 32i-MB Plus) |
| Power supply | AC200~220V 3 Phase |
| Positioning accuracy/Repeated Positioning accuracy | 0.005/+-0.003 mm |
| Machining Capacity Drilling/Tapping | ADC12 φ42 F0.2/M39×2.0 mm FC250 φ38 F0.15/M33×3.0 mm S45C φ32 F0.15/M27×2.0 mm |
