Özellikler
| Slide Travel XxYxZ-Axis | (360×2)×(420+100×2)×(300×2) mm |
|---|---|
| Height of Spindle Nose from Table | 250-550 mm |
| Table size (WxL) | 420×420×2mm |
| Tables Max.Load Capacity | 300×2kgs |
| Max. Spindle Speed | 12,000 min-1 |
| Rigid-Tap Speed | 5,000 min-1 |
| Spindle Motor | 11/7.5/5.5/3.7 KW |
| Rapid Traverse Rate X,Y,Z-Axis | 50,50,50 m/min |
| Shank of Tool Holders | BT30+P30T-II |
| Tool Change Method | Magazine direct system |
| No. of Tool Pot | 12×2(Op 15x2) |
| Max. Tool Diameter x Tool Length | φ80×200(Op φ80x180) mm |
| Max. Tool weight (total) | 2.5 kgs |
| Tool Change Time Tool to Tool/Chip to Chip | 1.0/2.3 sec |
| Max. Height of Machine | 2,415 mm |
| Height in Transporation | 2,200 mm |
| Size of Machine (Width, Depth) | 2,200×2,225 mm |
| Machine weight | 5,800 kgs |
| NC unit | (Op. FANUC 32i-MB Plus) |
| Power supply | AC200~220V 3 Phase |
| Positioning accuracy/Repeated Positioning accuracy | 0.005/+-0.003 mm |
| Machining Capacity Drilling/Tapping | ADC12 φ38 F0.2/M33×3.5 mm FC250 φ34 F0.2/M30×3.5 mm S45C φ28 F0.15/M24×3.0 mm |
