Özellikler
| Slide Travel X,Y,Z-Axis |
1,040 (520+520)x520x350 mm |
|---|---|
| Height of Spindle Nose from Table | 250~600mm |
| Table size (WxL) |
1,100 x 520 mm |
| Tables Max.Load Capacity | 400kgs |
| Max. Spindle Speed | 12,000 min-1 |
| Max. Speed Rigid Tapping | 5,000 min-1 |
| Rapid Traverse Rate X,Y,Z-Axis | 100,50,50 m/min |
| Shank of Tool Holders | BBT30+P30T-II |
| Tool Change System | Magazine direct system |
| No. of Tool Pot | 36 pos |
| Max. Tool Diameter x Tool Length | φ80x250mm |
| Max. Tool weight (total) | 2.5 kgs |
| Tool Change Time Tool to Tool/Chip to Chip | 1.0/2.2 seconds |
| Max. Height of Machine | 2,575mm |
| Min. Height of Machine | 2,250mm |
| Size of Machine (Width, Depth) | 1,900x2,345mm |
| Machine weight | 3,800 kgs |
| NC unit | FANUC 0i-MF Plus |
| Power-supply voltage | AC200V 3 Phase |
| Power capacity required | 15 KVA |
| Positioning accuracy/Repeated Positioning accuracy | 0.010/+-0.004 mm |
|
|
